Y82-100 15kW Horizontal Waste Paper Baler 1100x750mm With Conveyor
1 set
MOQ
Negotiable
Price
Y82-100 15kW Horizontal Waste Paper Baler 1100x750mm With Conveyor
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: WANSHIDA
Certification: CE and ISO9001
Model Number: Y82-100
High Light:

cardboard compactor machine

,

waste paper baling press machine

,

15kw horizontal waste paper baler

Payment & Shipping Terms
Packaging Details: Seaworthy packing
Delivery Time: 35 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 30 sets/month
Specifications
Product Name: Waste Paper Baler
Bale Size: 1100x750x(700-900)mm
Bale Weight: 350-500kg
Motor: 15kW
Cycle Time: 80s
Press Room Size: 1470x1200x3600mm
Efficiency: 4bales/h
Weight: 8000KGS
Product Description

Y82-100 Horizontal Waste Paper Baler 1100x750mm or Customize bale size With Conveyor



 1. Product:

Y82-100 Vertical waste cardboards balers can be used to press and bale many kinds of recyclable material, including papers, plastic films, cardboards, and cotton, etc. The baled materials are compactor and are smaller in size, which will reduce the storage space and shipping space, thus enabling you to gain the optimal revenue.

It is equipped with safety interlocks and PLC control system, so it is safe to use and easy to operate.



2. Technical Parameters:

Model Y82-100 Vertical Waste OCC Cardboards Baler
Balel Weight 350-500kgs
770-1210 pound
Bale Size 1100×750×(700-900)mm
43×30×(27.5-35)inch
Press Force 100Tons
Efficiency 4bales per hour
Motor Power 15kw
20Hp
Cycle time 80seconds
Dimensions 1470×1200×3600mm
57.8×47.2×141.7inch
Weight 8tons
17600Pound







3. More details:

Perfect for pressing OCC cardboards, scrap copper,scrap aluminum, scrap stainless steel.
Close the feeding material gate,the baler auto working.
With safety button on feeding material gate.
Big feeding room
Stable pressing with four pressing guide
Safety locking door and two safety protection system
Open the door,the electric will be shutted off.
Automatic steel chains ejecting bale system.
Bale size can be adjusted-DIY
Robust building
CE marked

This Y82 series waste baler is applicable for packing scrap carton, news paper, straws, waste plastics like PET bottle, plastic film, recycle case, etc.


4. Application:
Made by adopting internationally advanced technology and equipment, our waste paper balers are mainly used to compact waste papers and other similar loose materials in normal state and then use specialized packing string to bale them, making them smaller in size. In this way, these waste papers or other loose materials will take up less shipping space, thus reducing the transportation cost.


5. Features:
Our waste paper baler uses hydraulic drive mode. It is designed with rational and compact structure, and it is easy to operate and safe to use.
Characteristics of our waste paper baler include small size, light weight, small inertia, low running noise, stable running, reliable hydraulic characteristic, high operating efficiency, low energy consumption, easy installation and operation, and strong environmental adaptive ability, etc.
This vertical waste baler can not only be used to bale waste papers, but also be applied to bale or compact similar loose materials.





6. Photos:

Y82-100 15kW Horizontal Waste Paper Baler 1100x750mm With Conveyor 0Y82-100 15kW Horizontal Waste Paper Baler 1100x750mm With Conveyor 1Y82-100 15kW Horizontal Waste Paper Baler 1100x750mm With Conveyor 2Y82-100 15kW Horizontal Waste Paper Baler 1100x750mm With Conveyor 3
