Automatic Waste Paper Baling Machine , Waste Carton Baler Horizontal Baling Press
1 set
MOQ
Negotiable
Price
Automatic Waste Paper Baling Machine , Waste Carton Baler Horizontal Baling Press
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: WANSHIDA
Certification: CE and ISO9001
Model Number: Y82/W-50A
High Light:

horizontal baling press

,

horizontal cardboard baler

Payment & Shipping Terms
Packaging Details: Seaworthy packing
Delivery Time: 35 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10 sets/month
Specifications
Product Name: Horizontal Baling Machine
Bale Weight: 350KGS
Bale Size: 600x600x1000mm Or Customized
Motor: 20kW
Dimension: 7000x2000x1980mm
PLC Brand: Mitsubishi Or Siemens
Output Capacity: 2-4t/h
Strapping Wire: 4 Wires
Product Description

Waste Carton Baling Machine Press baler for newspaper cardboards





1. Description:

This Y82W-50A automatic waste paper baler is commonly applied in baling loose materials, such as scrap paper, waste carton, news paper, waste plastic, PET bottles, plastic film and recycle case, straws, etc.



2.Technical Parameters:

Model Y82W-50A
Bale weight 450kg
Bale size (W×H×L) 600×600×1000
Press force 50T
Output capacity 2-4T
Motor power 20kw
Strapping wire 4 wires
Dimensions 7000*2000*1980mm
Weight 8.5ton







3. Features

1) Controlled by PLC system, this baler is equipped with the touch screen for window monitoring, error warning with synchronous indicator diagram, bale length setting and other operations.

2) The design of floating clamping device on the upper, left and right directions facilitates the automatic distribution of four sided pressure. It makes the machine capable of baling a wide range of materials.

3) Equipped with 6m long conveyor belt, this automatic waste paper baler is able to load and feed materials automatically. Moreover, it supports automatic binding performance, improving the baling speed.

4) The pushing cylinder and the bale ejector are connected reliably in spherical structure, prolonging the longevity of oil seal.

5) There are several shear blades distributed at the feeding inlet increasing the cutting efficiency.

6) Our automatic waste paper baler adopts the hydraulic circuit design with low noise to increase the working efficiency and decrease the failure rate.

7) It can be easily mounted without any foundation.

8) The specific dimensional design of the compress room and the bale is available as required.



4. Optional Extra

Conveyor Feeding
Oil heater
Oil cooler

Diesel Engine Drive



5. Applications

OCC

Carton

Cardboard

Dry Soft Plastic

PET Bottles

Plastic film

White Goods

Shred paper

News Paper

Scrap Tire

HDPE Jars





6. Photos:

Automatic Waste Paper Baling Machine , Waste Carton Baler Horizontal Baling Press 0Automatic Waste Paper Baling Machine , Waste Carton Baler Horizontal Baling Press 1
